Single Jersey |
Fleece
|
Terry(Front-Face
Loop Back-Fase Loop)
|
|
|
|
| SPECIAL
FEATURES: |
 |
The cylinder and base big
gear uses auto-cycle lubricating oil filter system, high precision,
durable, The cylinder and base big gear uses auto-cycle lubrication
or filter system, high precision, durable, prevents high temperature,
stabilizes the precision of the concentric circles, keeping fabrics
even. |
|
The cam on the upper and lower
dials are manufactured from special steel, and computer processing
allows high precision. The design has a four stage micro tuning structure
for easy regulation of fabric weight. Furthermore, the cam are interchangeable
at any time to speed up knitting production. |
|
It uses a variable frequency
motor with touch style controls, and by using microprocessor controls
to reduce power consumption, makes best use of the horsepower of the
motor. |
|
Micro computerized injection
oil lubricator has been improved to a hydraulic jetspray-dripping
type, and it provides a lubricating effect for the dial tract. |
|
The machine will auto stop
and the indicating lamp will flash, indicating the parts which breakdown
during the yarn is in abnormal tension. |
|
SPECIFICATIONS
|
|
CYLINDER
DIA.:
|
26"-40"
|
|
GUAGE:
|
2.5G-40G
|
|
FEEDERS:
|
48-144
|
|
R.P.M.
|
18-35
|
|
MOTOR
(HP):
|
5-7
1/2
|
|
WOODEN
CASE:
|
2500
x 2100 x 2700mm. N./G. Weight 1920/2040kgs
|
|
|
